Title, Added, Status, Last reviewed
Title Added Status Last reviewed
Start Process Cloud Component v3.0.0 Experimental 2019-01-08

Start Process Cloud Component

Starts a process.

adf-start-process

Basic Usage

<adf-cloud-start-process
   [appName]="YOUR_APP_NAME">
</adf-cloud-start-process>

Class members

Properties

Name Type Default value Description
appName string (required) Name of the app.
maxNameLength number Maximum length of the process name.
name string "" Name of the process.
processDefinitionName string Name of the process definition.
showSelectProcessDropdown boolean true Show/hide the process dropdown list.
variables Map<string, object>[] Variables to attach to the payload.

Events

Name Type Description
cancel EventEmitter<ProcessInstanceCloud> Emitted when the starting process is cancelled
error EventEmitter<ProcessInstanceCloud> Emitted when an error occurs.
success EventEmitter<ProcessInstanceCloud> Emitted when the process is successfully started.

Details

Starting a process with a default name and a pre-selected process definition name

 <adf-cloud-start-process
      [appId]="YOUR_APP_ID"
      [name]="PROCESS_NAME"
      [processDefinitionName]="PROCESS_DEFINITION_NAME">
 </adf-cloud-start-process>

You can use the processDefinitionName property to select which process will be selected by default on the dropdown (when there is more than one process to choose from). Use the name property to set the name shown on the dropdown item.

If the app contains only one process definition, this process definition will be selected by default
